SYMON FÜR EMC DATADOMAIN

SYMON Monitoring Plugin für EMC Data Domain überwacht die Hardware, die CPU Auslastung, die Netzwerkanschlüsse und den Status der Festplatten. Es liefert Werte zum belegten Datenvolumen und Kompressionsfaktor, sowie Informationen zum Verkehr am Netzwerk, Status der Replikation und zur Service Überwachung (DD Boost, VTL, ...). Statusberichte aller Netzwerk-Ports und des Datenverkehrs sind jederzeit abrufbar und für Trend- und Performanceanlysen essentiell.
Check Beschreibung
Data Collector Main data collector check.
Alert Check Checks for unhandled alerts on the Data Domain.
CIFS Statistics Checks for CIFS Statistics.
CIFS Status Check Checks for CIFS Status.
Compression Checks for the compression factor and reduction.
CPU Checks for DataDomain CPU Usage.
DDBOOST Checks for DDBoost Status.
Disk Status Checks for the status of the disks.
Disk utilization and throughput Checks for utilization and throughput of the disk.
Enclosure Checks for Enclosure Status.
FAN Checks for DataDomain Fan Status.
Filesystem Checks for Filesystem Status.
INFO Checks for node information.
Interface Checks for Interface Status.
Interface Statistics Checks for Interface Statistics (MB/s).
Memory Checks for memory and SWAP usage of the System.
NFS Statistics Checks for NFS Statistics.
NFS Status Checks for NFS Status.
NVRAM Checks for NVRAM Average Time.
Powersupply Checks for Powersupply Status.
Replication Checks for the status of an replication.
Replication Statistics Checks for Replication Statistics.
Space Usage Checks for Data Domain Space Usage
VTL Status Checks for VTL Status.
The Monitoring Plugin for DataDomain consists of a data collector (datadomain_collector) and various checks for different components of the EMC DataDomain system. The Collector of the Monitoring Plugin for DataDomain defines the checking interval. If you want to check some components every 15 minutes you have to set the checking interval of the collector to 15 minutes. The checking interval of the collector has to be the same as the smallest of all components.
Data Domain Systems
  • 5.4
  • 5.5
  • 5.6
  • 5.7
Platforms
  • EL 6/7
  • Supported OP5 release
Software
  • nagios Version 3.5.1 and Version 4.0.8 or newer
  • python2.6/2.7
Python libraries
  • lxml
  • subprocess
  • sys
  • re
  • os
  • time
  • paramiko
Our default package is for python 2.6 if you need a package for python 2.7, please contact us.
Data Domain
  • ssh-access (port 22)
  • readonly user
  • password / ssh-key
For usage without a password, you will have to install the public ssh-key, of the nagios daemon users, on your Data Domain.
Release 2.0.7
  • BugFix - Replication Check - Status Licensed & Disabled
Release 2.0.6
  • BugFix - CPU Check - value validation
  • BugFix - Data Collector - invalid values from DataDomain
  • BugFix - Compression Check - empty values
  • BugFix - Collector - DDOS Version 5.5.0.x
  • BugFix - Collector - CPU for Version 5.4.1.x
  • FeatureEnhancement - information check - In case of missing information, shows the remaining information.
Release 2.0.5
  • Documentation improvements
Release 2.0.4
  • Enhancement - Data Domain OS 5.4.1.1
  • BugFix - cifs statistics
  • Enhancement - Data Domain OS 5.4.0.8
Release 2.0.3
  • BugFix - disk status check - overall check correction
  • BugFix - fan status check - overall check correction
  • BugFix - power status check - overall check correction
Release 2.0.2
  • BugFix - alert check - counter correction
Release 2.0.1
  • BugFix - collector - fan state
Release 2.0.0
  • 2.0 release
