SYMON FÜR EMC VNX BLOCK

SYMON Monitoring Plugin für EMC VNX Block überwacht die Hardware Komponenten des Storage, die Auslastung der Pools, sowie den Cache und das Tiering.
Check Beschreibung
Data Collector Main data collector check.
Pool Collector Pool data collector check.
Cache Mirror Checks for VNX Cache Mirror
Cache Page Checks for Cache Page Size
Cache Checks for Read or Write Cache Size
Fast Cache FAST Cache Check for MB/s Flushed
LUN Checks for LUN ownership status.
Model Displays the model number.
Power Supply Checks for PowerSupply Errors
SP Agent Version Displays the SP agent version.
SP Disk Checks for SP disk errors.
SP ID Displays the SP SCSI ID
SP MEM Checks for SP total memory.
SP Port Checks for SP Port State.
SP Serial Displays the SP Serialnumber
Standby Power Supply Checks for Standby Power Supply Errors.
SP State Checks the Service Processor State.
Pool State Checks the Pool State.
Pool Usage Checks the Pool usage.
The Monitoring Plugin for VNX consists of a data collector (centera-collector) and various checks for different components of the EMC VNX system. The Collector of the Monitoring Plugin for VNX defines the checking interval. If you want to check some components every 15 minutes you have to set the checking interval of the collector to 15 minutes. The checking interval of the collector has to be the same as the smallest of all components.
VNX Block Systems
  • 5.33
Platforms
  • EL 6/7
  • Supported OP5 release
Software
  • nagios Version 3.5.1 and Version 4.0.8 or newer
  • python2.6/2.7
  • current version of naviseccli
Python libraries
  • lxml
  • subprocess
  • sys
  • re
  • os
  • getopt
  • time
VNX Access
  • To enable access for Nagios to the VNX System, you need a naviseccli security file for the Nagios user.
1.2.9
  • Enhancement: Added Pool Function
1.2.8
  • Enhancement: lun check - list affected luns
1.2.6
  • Bugfix
1.2.4
  • Bugfix
1.2.0
  • Statusdata now in XML
1.1.0
  • Added Path Parameter
1.0.0
  • First release
